Desktop Semi-automatic Pump Bottle Capping Machine
Machine overview and key points for quotation.
This machine is suitable for different kinds of bottle caps like spray bottles,smoking oil bottle caps.The suitable cap size is 20-60mm.It widens the application range,this greater than other capping machine.
Throughput
20–60 bottles/min (depending on bottle and caps)
Target speed depends on product, pack and operator workflow.
Format range
Formats adjustable (bottle/closure dependent)
We’ll configure the machine to your bottle, closure and fill volume.
Utilities
AC220V/110V 50–60HZ
We’ll confirm voltage, air and installation requirements for your site.
Machine gallery
Auto‑scrolling. Hover to pause.
Tip: Reorder images in the product manager — this carousel follows your order.
Specifications
Reference specification table. Final configuration may vary with options and scope.
| Parameter | Value |
|---|---|
| Model | LU-XG6100 |
| Bottle Height | 100–300 mm |
| Bottle Caps Diameter | 20–60 mm (Max Custom Size 90 mm) |
| Working Speed | 20–60 bottles/min (depending on bottle and caps) |
| Working Voltage | AC220V/110V 50–60HZ |
| Power | 120W |
| Working Mode | Manual / Automatic |
| Machine Size | 475 × 350 × 550 mm |
| Net Weight | 28 kg |
| Package Size | 665 × 365 × 560 mm |
| Gross Weight | 35.5 kg |
| Size of Air Compressor Connector | OD 8 mm |
CAD / Dimensions
Footprint and dimension reference for planning, guarding and line integration.
No CAD drawing available for this machine.
Site requirements
- Confirm access for delivery, positioning and commissioning.
- Verify utilities and air supply requirements during specification.
- Allow clearance for guarding, maintenance and future upgrades.
