Machine overview
Detergent Bottles Double-Sided Labeling Machine
Machine overview and key points for quotation.
Introducing our advanced double-sided labeling machine, designed for flat bottles. This versatile machine can easily switch between single-sided and double-sided labeling by changing the labeling structure, expanding its application range. Made of high-quality materials, it can be seamlessly integrated with automatic filling and capping machines to create a complete packaging process. This labeling machine is easy to operate, stable and efficient, and is the perfect solution to meet your packaging needs.
Throughput
≤35bpm
Target speed depends on product, pack and operator workflow.
Format range
Formats adjustable (bottle/closure dependent)
We’ll configure the machine to your bottle, closure and fill volume.
Utilities
3000W AC 220V±2% 50/60Hz (single phase)
We’ll confirm voltage, air and installation requirements for your site.
Machine gallery
Auto‑scrolling. Hover to pause.
Tip: Reorder images in the product manager — this carousel follows your order.
Specifications
Reference specification table. Final configuration may vary with options and scope.
| Parameter | Value |
|---|---|
| Model | LU-TB600D |
| Power specification | 3000W AC 220V±2% 50/60Hz (single phase) |
| Labeling speed | ≤35bpm |
| Labeling accuracy | ±1.0mm up and down, ±1.0mm left and right |
| Center paper roll size | (R) 76mm (or customized upon request) |
| Label roll outer diameter | MR 100~350mm (or customized upon request) |
| Label width | (W) 10~130mm (or customized upon request) |
| Label length | (L) 15~300mm (or customized upon request) |
| Object size | (L) 20~300mm x (W) 20~120mm x (H) 60~320mm |
CAD / Dimensions
Footprint and dimension reference for planning, guarding and line integration.
No CAD drawing available for this machine.
Site requirements
- Confirm access for delivery, positioning and commissioning.
- Verify utilities and air supply requirements during specification.
- Allow clearance for guarding, maintenance and future upgrades.
