ZS-GTW2D Dual-Head Liquid Filling Machine
Machine overview and key points for quotation.
The Lancing UK LU-GTW2D Quantitative Weighing and Filling Machine is designed for high-volume liquid filling with precision and speed. Featuring dual filling heads and an integrated weighing scale, it delivers accurate fills from 10–30L with ±0.2% precision. Its PLC control panel ensures intuitive operation, while the robust construction supports long-term industrial use. Ideal for chemicals, cleaning agents, edible oils, and other bulk liquid products, this machine achieves up to 360 bottles per hour (based on 4L volume), making it a reliable solution for efficient, large-scale filling tasks.
Throughput
300–360 BPH (based on 4L filling volume)
Target speed depends on product, pack and operator workflow.
Format range
10–30L (can be customized)
We’ll configure the machine to your bottle, closure and fill volume.
Utilities
110/220V, 50–60Hz, 2.2kW
We’ll confirm voltage, air and installation requirements for your site.
Machine gallery
Auto‑scrolling. Hover to pause.
Tip: Reorder images in the product manager — this carousel follows your order.
Specifications
Reference specification table. Final configuration may vary with options and scope.
| Parameter | Value |
|---|---|
| Model | LU-GTW2D |
| Voltage | 110/220V, 50–60Hz, 2.2kW |
| Filling range | 10–30L (can be customized) |
| Filling speed | 300–360 BPH (based on 4L filling volume) |
| Filling accuracy | ±0.2% |
| Feeding pump | Gear pump |
| Filling heads quantity | 2 |
| Machine size (L×W×H) | About 960×970×1610mm |
| Packaging size | About 1110×1110×1730mm |
| Packaging weight | About 226kg |
CAD / Dimensions
Footprint and dimension reference for planning, guarding and line integration.
No CAD drawing available for this machine.
Site requirements
- Confirm access for delivery, positioning and commissioning.
- Verify utilities and air supply requirements during specification.
- Allow clearance for guarding, maintenance and future upgrades.
