Machine overview
ZS‑SV4HS 4‑Head Servo Piston Liquid Filling Machine
Machine overview and key points for quotation.
The Lancing UK ZS‑SV4HS is a high‑precision 4‑head liquid filling machine powered by a servo motor for exceptional accuracy. Controlled by a PLC system, it offers smooth, reliable operation and can be tailored to meet diverse production needs. Ideal for food, cosmetics, and daily chemical industries, it handles a wide range of liquid products with consistent, efficient performance. Machine Specifications — Model ZS‑SV4HS Parameter Details Model ZS‑SV4HS Machine Voltage 110 V / 220 V, 50–60 Hz Power Approx. 6 kW Filling Range 100 – 1000 ml (customizable) Filling Speed Approx. 15 – 30 bottles/min (varies by bottle size & material) Filling Accuracy Approx. ±0.5 % Air Pressure 0.5 – 0.8 MPa Conveyor Belt Size Approx. 114 × 2000 mm (W × L) Machine Weight Approx. 130 kg Package Size Approx. 2070 × 760 × 1670 mm Package Weight Approx. 275 kg
Throughput
Configurable (confirm during quote)
Target speed depends on product, pack and operator workflow.
Format range
Formats adjustable (bottle/closure dependent)
We’ll configure the machine to your bottle, closure and fill volume.
Utilities
Site utilities to be confirmed
We’ll confirm voltage, air and installation requirements for your site.
Machine gallery
Auto‑scrolling. Hover to pause.
Tip: Reorder images in the product manager — this carousel follows your order.
Specifications
Reference specification table. Final configuration may vary with options and scope.
No specifications listed yet.
CAD / Dimensions
Footprint and dimension reference for planning, guarding and line integration.
No CAD drawing available for this machine.
Site requirements
- Confirm access for delivery, positioning and commissioning.
- Verify utilities and air supply requirements during specification.
- Allow clearance for guarding, maintenance and future upgrades.
Talk to a specialist
We’ll confirm suitability, options, integration, and realistic throughput for your product.
