Machine overview
Tablet VFFS Bagger Granule Filling Counting Sealing Machine
Machine overview and key points for quotation.
Tablet VFFS Bagger Granule Filling Counting Sealing Machine , sales and related technical services of modern high-tech enterprises. Opens in a new window.
Throughput
30–50 bags/min
Target speed depends on product, pack and operator workflow.
Format range
8 pieces/bags (customized)
We’ll configure the machine to your bottle, closure and fill volume.
Utilities
1.1KW
We’ll confirm voltage, air and installation requirements for your site.
Machine gallery
Auto‑scrolling. Hover to pause.
Tip: Reorder images in the product manager — this carousel follows your order.
Specifications
Reference specification table. Final configuration may vary with options and scope.
| Parameter | Value |
|---|---|
| Model | LU-SLFK80 |
| Power | 1.1KW |
| Power Supply Voltage | 220V 50Hz–60Hz |
| Measuring Range | 8 pieces/bags (customized) |
| Granule Size | 3.2–3.8mm thickness / 5mm diameter (Need sample for custom) |
| Measuring Method | Counting |
| Unloading Method | Through the counting disc |
| Packing Speed | 30–50 bags/min |
| Bag Size | 40–190(L) × 40–100(W) (Customized) |
| Sealing Form | Three-side sealing, back sealing (Customized) |
| Packing Material | Paper/polyethylene, aluminum foil/polyethylene, nylon/tea filter paper, etc. |
| Film Thickness | 0.04–0.08mm |
| Film Width Range | 220mm |
| Machine Size | About 620 × 780 × 1800mm |
CAD / Dimensions
Footprint and dimension reference for planning, guarding and line integration.
No CAD drawing available for this machine.
Site requirements
- Confirm access for delivery, positioning and commissioning.
- Verify utilities and air supply requirements during specification.
- Allow clearance for guarding, maintenance and future upgrades.
