ZS-VTGF8A Automatic Viscous Liquid Filling Machine
Machine overview and key points for quotation.
The LU-VTGF8A is a high-performance 8-head liquid and paste filling machine equipped with servo-driven gear pumps. Designed for medium to large volume applications, it supports a wide filling range from 50ml to 5000ml, making it ideal for products like shampoo, conditioner, lotion, and detergent. With a robust stainless-steel build, intelligent touch screen control, and working speed of up to 40 bottles/min, this machine ensures fast, accurate, and stable filling with minimal downtime. Customizable bottle sizes and high filling precision of ±0.5% make it perfect for both industrial and commercial filling operations.
Throughput
Configurable (confirm during quote)
Target speed depends on product, pack and operator workflow.
Format range
Formats adjustable (bottle/closure dependent)
We’ll configure the machine to your bottle, closure and fill volume.
Utilities
Site utilities to be confirmed
We’ll confirm voltage, air and installation requirements for your site.
Machine gallery
Auto‑scrolling. Hover to pause.
Tip: Reorder images in the product manager — this carousel follows your order.
Specifications
Reference specification table. Final configuration may vary with options and scope.
| Parameter | Value |
|---|---|
| Model | LU-VTGF8A Power Supply: 110/220V 50-60HZ 5KW Filling Pump: Gear Pump Max Flow Rate: 120L Filling Range: 50–5000 ml Bottle Size: Customizable Working Speed: About 24–40 bottles/min (based on 5L filling volume) Filling Accuracy: About ±0.5% Air Pressure: About 0.5–0.8 MPa Machine Size: About 492012701950 mm (LWH) Package Size: About 272013502120 mm Package Weight: About 630 kg |
| Gear pumps are commonly used for transferring | Lubricating oils (e.g., machinery oil, hydraulic oil, engine oil) Fuels (e.g., diesel, heavy oil, light oil) Chemical liquids (e.g., resin, paint, additives) Food-grade liquids (e.g., syrup, chocolate paste, vegetable oil) — requires a stainless steel food-grade gear pump Polymers and viscous materials (e.g., glue, bitumen) 👉 If you need a food-grade filling machine, feel free to contact us for customized solutions! |
CAD / Dimensions
Footprint and dimension reference for planning, guarding and line integration.
No CAD drawing available for this machine.
Site requirements
- Confirm access for delivery, positioning and commissioning.
- Verify utilities and air supply requirements during specification.
- Allow clearance for guarding, maintenance and future upgrades.
