Machine overview
ZS-VTRP2A Automatic Paste Filler Sauce Filling Machine
Machine overview and key points for quotation.
Introducing our cutting-edge Precise Automatic Filling Machine, revolutionizing your production capabilities. This advanced machine combines the power of servo-driven technology with a rotor pump, delivering unparalleled accuracy and efficiency to meet your diverse filling needs.
Throughput
About 35 bottles/min (dependent on bottle size and liquid)
Target speed depends on product, pack and operator workflow.
Format range
50-1500ml
We’ll configure the machine to your bottle, closure and fill volume.
Utilities
220V/110V, 50/60Hz
We’ll confirm voltage, air and installation requirements for your site.
Machine gallery
Auto‑scrolling. Hover to pause.
Tip: Reorder images in the product manager — this carousel follows your order.
Specifications
Reference specification table. Final configuration may vary with options and scope.
| Parameter | Value |
|---|---|
| Model | LU-VTRP2A |
| Voltage | 220V/110V, 50/60Hz |
| Machine Pump | Rotor Pump |
| Filling Range | 50-1500ml |
| Filling Speed | About 35 bottles/min (dependent on bottle size and liquid) |
| Filling Accuracy | ≤ ±1% |
| Filling Nozzle Diameter | OD 25mm |
| Suitable Bottle Height | 30mm-250mm |
| Suitable Bottle Diameter | 30mm-110mm |
| Hopper Capacity | About 70L |
| Machine Size | 2000 × 791 × 1084mm |
| Machine Weight | 200kg |
CAD / Dimensions
Footprint and dimension reference for planning, guarding and line integration.
No CAD drawing available for this machine.
Site requirements
- Confirm access for delivery, positioning and commissioning.
- Verify utilities and air supply requirements during specification.
- Allow clearance for guarding, maintenance and future upgrades.
Talk to a specialist
We’ll confirm suitability, options, integration, and realistic throughput for your product.
Enquire about this machine
Send a message and we’ll respond with configuration options, pricing guidance and lead times.
